1999 Picanol Gamma

Contact us for price

North Carolina

orCall 864-720-9333

Description

53 Picanol Gamma-4-R

Year: 1999
Width: 190cm

With Staubli 2670 dobby with 20 lever capacity and avg of 8 harness frames per loom, 4 color with 2 Picanol Luna weft accumulators, 4 stop motion bars with droppers as fitted
all looms with Sumo motor, allowing for speed adjustment with push of a button
33 looms upgraded in 2014 with LDEC system (20 no LDEC)
29 w 16 harness drives
24 w 8 harness drives
21 looms with side tuckers
1.2 beams each
Batching unit with lighted inspection board
Machines are running synthetic fabrics, only using OEM parts
Looms with side tuckers running 500rpm
Looms without sidee tuckers running at 550rpm
Min fabric width 51” and max fabric width of 75”
Nearest airport Greensboro, NC, USA or alternate Charlotte, NC, USA
Very top condition

Floor space requirements
loom only (no batching unit)
4.5m x 2m

Loom with batching unit
4.5m x 3.66m

Floor space required by 12 looms in 3x4 configuration including batching unit
22mx15.24m

Pics, price & video on request
ccoker@cokerandassociatesllc.com

Loom # Serial # LDEC Shafts in Dobby -Side tucking

1216 244510 No 16 Yes
1214 244479 No 16 Yes
1206 244505 No 16 No
1204 244507 No 16 Yes
1202 244503 Yes 16 No

1201 244513 Yes 16 Yes
1203 244500 Yes 16 Yes
1205 244502 No 16 Yes
1207 2 44511 Yes 16 Yes

1209 244509 No 16 Yes
1211 244506 Yes 16 Yes
1213 244508 No 16 Yes
1215 244504 Yes 16 Yes

1253 246770 No 8 No
1254 246769 No 8 No
1255 246768 Yes 8 No
1256 246765 No 8 No

1246 246766 No 8 No
1248 246764 Yes 8 No
1250 246757 Yes 8 No
1252 246749 No 8 No

1251 246767 No 8 No
1249 246762 No 8 No
1247 246763 No 8 No
1245 246748 Yes 8 No

1240 246752 Yes 8 No
1238 246756 Yes 8 No
1236 246755 Yes 8 No
1234 256754 Yes 8 No

1233 246758 Yes 8 No
1235 246760 No 8 No
1237 246762 No 8 No
1239 246750 Yes 8 No

1241 246751 No 8 No
1242 246747 Yes 8 No
1243 246759 Yes 8 No
1244 246753 Yes 8 No

1218 244857 Yes 16 Yes
1220 244859 Yes 16 Yes
1222 244972 No 16 Yes
1224 244870 No 16 Yes
1226 244868 Yes 16 Yes
1228 244862 Yes 16 Yes
1230 44860 Yes 16 Yes
1232 244861 Yes 16 Yes

1231 244867 Yes 16 No
1229 244864 No 16 No
1227 244865 No 16 No
1225 244863 Yes No
1223 244858 Yes No
1221 244869 Yes 16 Yes
1219 244866 Yes 16 No
1217 244928 Yes 16 Yes

Specifications

ManufacturerPicanol
ModelGamma
Year1999
ConditionUsed
